3000 Soft-Grip® Series Hand-Tite® DIY Keyless

Model Name: 3010-1S 3010-2S 3013-2S

Consumer Application, Recommended For Consumer DC Drill Or AC Drill.

Features
series 8000

Jacobs Hand-Tite® Technology

Quick and Easy chuck operation.

series 8000

“Soft-Grip” Technology

Soft Rubber Sleeve, easier hand tightening, more comfortable. Users can apply more tightening torque which provides higher gripping force..

series 8000

Color Flexibility and Design

Various customized color, well match drill color system.

series 8000

“Click” Technology (Optional)

Provides audible and tactile feedback when chuck is properly tightening.

series 8000

"Hammer" Technology (Optional)

A positive locking mechanism which prevents loosening in hammer drill application.

Specification
Model PN Sleeve Capacity(in) Capacity (mm) Mount L (in/mm) Dia (in/mm) Feature Package
3010-2S *32819 2 Soft 0.04"-3/8" 1-10mm 3/8-24 UNF 2.18"/55.4mm 1.91"/48.5mm Rotary Bulk
3010-1S *32916 1 Soft 0.04"-3/8" 1-10mm 3/8-24 UNF 2.17"/55.1mm 1.84"/46.7mm Rotary Bulk
3010-2S *33125 2 Soft 0.04"-3/8" 1-10mm 1/2-20 UNF 2.28"/57.9mm 1.91"/48.5mm Hex Head Bulk
3013-2S *32712 2 Soft 1/16"-1/2" 1.5-13.0mm 1/2-20 UNF 2.47"/62.7mm 1.96"/49.7mm Hammer Bulk
3013-2S *33130 2 Soft 1/16"-1/2" 1.5-13.0mm 1/2-20 UNF 2.65"/67.2mm 1.96"/49.7mm Hex Head Bulk
* OEM market
More>>

Note: Products pictures reference only, please prevail in kind.
