3000 Soft-Grip® Series Hand-Tite® DIY Keyless
Model Name:
3010-1S
3010-2S
3013-2S
Consumer Application, Recommended For Consumer DC Drill Or AC Drill.
Features
Jacobs Hand-Tite® Technology
Quick and Easy chuck operation.
“Soft-Grip” Technology
Soft Rubber Sleeve, easier hand tightening, more comfortable. Users can apply more tightening torque which provides higher gripping force..
Color Flexibility and Design
Various customized color, well match drill color system.
“Click” Technology (Optional)
Provides audible and tactile feedback when chuck is properly tightening.
"Hammer" Technology (Optional)
A positive locking mechanism which prevents loosening in hammer drill application.
Specification
| Model | PN | Sleeve | Capacity(in) | Capacity (mm) | Mount | L (in/mm) | Dia (in/mm) | Feature | Package |
|---|---|---|---|---|---|---|---|---|---|
| 3010-2S | *32819 | 2 Soft | 0.04"-3/8" | 1-10mm | 3/8-24 UNF | 2.18"/55.4mm | 1.91"/48.5mm | Rotary | Bulk |
| 3010-1S | *32916 | 1 Soft | 0.04"-3/8" | 1-10mm | 3/8-24 UNF | 2.17"/55.1mm | 1.84"/46.7mm | Rotary | Bulk |
| 3010-2S | *33125 | 2 Soft | 0.04"-3/8" | 1-10mm | 1/2-20 UNF | 2.28"/57.9mm | 1.91"/48.5mm | Hex Head | Bulk |
| 3013-2S | *32712 | 2 Soft | 1/16"-1/2" | 1.5-13.0mm | 1/2-20 UNF | 2.47"/62.7mm | 1.96"/49.7mm | Hammer | Bulk |
| 3013-2S | *33130 | 2 Soft | 1/16"-1/2" | 1.5-13.0mm | 1/2-20 UNF | 2.65"/67.2mm | 1.96"/49.7mm | Hex Head | Bulk |
| * OEM market | |||||||||
Note: Products pictures reference only, please prevail in kind.
